To set a static MAC address for a virtual machine, you can edit the configuration file of the virtual machine by using the vSphere Web Client. You can manually assign a MAC address to a virtual machine. You might want to assign a MAC address to guarantee that the same address is assigned to a virtual machine every time it powers on, even it is moved, or to be sure that a unique MAC address is provided for each virtual machine in a networked environment.
I wish to distribute a VMWare VM for users (who are technically challenged and unable to install a complex product). Users may run several instances of the VM in their environment, so it's essential that each VM have NIC's with unique MAC addresses.
Is there a way to distribute the VM in such a way that on first boot if forces new MAC addresses onto the NIC's?
Vmware Automatic Vs Manual Mac Address Free
If users just add the VM to their inventory and select 'moved' instead of 'copied' then they get the same MAC's (I believe).
I'm using VMWare WOrkstation 12 in case that matters.
TSGTSGVmware Automatic Vs Manual Mac Address 2016
1 Answer
The canonical 'correct' way to distribute VM images for VMware vSphere is to distribute .ova files created using ovftool, and then use the vSphere GUI to install the .ova file. This automatically distributes a 'copied' version of the virtual machine that has a different MAC address when deployed. However, there is a way to do the job if you're going to instead distribute a zipped up VMware Workstation directory. What you need to do is, immediately before you zip up the directory, is first copy the .vmx file someplace else. Then edit the vmx file and look for a line that looks like
Remove that line from the vmx file.
Then zip it up and distribute it. That should give you copy of the virtual machine that does not have a built in MAC address and that should generate a new MAC address upon deployment. (This is assuming a VM with a single Ethernet interface). Then copy the original .vmx file back into place.
Automatic Vs Manual Cars
Note that for certain operating systems, such as Red Hat Enterprise Linux 6, there are udev rules that tie a specific Ethernet interface to a specific MAC address. These must be removed to allow eth0 to come up after the deployment. If your operating system is one of those, that is a separate question.
